MTW-ZS15 is a self-locking box bottom former packing machine which controlled by PLC and operated from HIMI system. It is the box former and bottom locker without glue nor adhesive taper sealing.
Configuration:
1.Motor: GPG
2.PLC: Siemens
3.Sensor:Leuze
4.Touch Panel: Siemens
5.Pneumatic parts: Shako
| Model | MTW-ZS15 |
| Power supply | 220V 50/60HZ |
| Packing speed | 10~12TRAY/MIN |
| Packing material | Corrugated case blanks |
| Packing size | Diameter：L365*W350*H60mm(Customized build) |
| Table height | 650mm |
| Air sauce | 0.4~0.6Mpa |
| Air consumption | 0.2nm³/min |
| Machine weight | 500~800KG |
| Machine dimension | L1900×W1600×H1900mm |
